COSA (Custom on Standard Architecture)は、幅広いプラットフォームと機能をサポートし、バックグラウンド・ビルトイン・テストによる高い機能密度を実現します。
70種類以上のマルチファンクションI/Oボードからシステム要件に応じた機能を選択することで、必要な基板数の削減、消費電力の削減、SBCで必要な処理のオフロードを実現します。
製品型番 | Information | カテゴリ | フォームファクタ |
---|
Time Sensitive Network | Real-time, low-latency Ethernet communication | Function Modules (VPX, VME, cPCI, PCIe) | |
October Newsletter | Reduce Size, Weight and Power | | |
Intelligent Power Monitor | Provides a precise, instrument grade, digital analysis of input power lines | 堅牢型電源 | |
COSA | High Functional Density, Built in Test | マルチファンクション I/O ボード | |
68PPC3 | NXP®, QorIQ® T2080 quad-core processor | シングルボードコンピューター (SBC) | 3U VPX |
VPX55-32HSU | High-performance DC/DC converter that delivers up to 100 watts | 堅牢型電源 | 3U VPX |
5330A | Synchro/Resolver Simulator | シンクロ / レゾルバ | 計測器 |
VPX55H-3 | 500 Watts DC/DC | 堅牢型電源 | 3U VPX |
COSA Modules | Analog and Digital, Measurement and Simulation, Communication | マルチファンクション I/O ボード | |
65CS4 | Synchro/Resolver Measurement and Simulation | シンクロ / レゾルバ | VXI |
Actuator Interface Units (AIU) | Interface for sensors that indicate temperature, flow, level or pressure | 堅牢型COTSシステム | System |
MIL-STD-1553 | 1, 2 or 4-channel and dual-redundant | Function Modules (VPX, VME, cPCI, PCIe) | |
68INT4 | Intel® Xeon® Processor E3-1505L v6 with HDMI/DVI output (4K) | シングルボードコンピューター (SBC) | 3U VPX |
64PW2 | PWM - Servo Amplifier | PWM- Servo Motor Drives | VME |
68SR1 | Solid-State Power Controller Relay Board | Solid State Power Controller | 3U VPX |
68INT5 | Intel® Xeon® Processor E-2276ME with HDMI/DVI Output (4K) | シングルボードコンピューター (SBC) | 3U VPX |
68INT6 | 3U VPX SBC Tiger Lake Intel Processor | シングルボードコンピューター (SBC) | 3U VPX |
68INT6H | Intel® Xeon® W Processor (Tiger Lake) | シングルボードコンピューター (SBC) | 3U VPX |
ARINC 429 | 12 programmable channels | Function Modules (VPX, VME, cPCI, PCIe) | |
68G6 | 高度なセキュリティ オプション、継続的なバックグラウンド ビルトイン テスト (BIT) | マルチファンクション I/O ボード | 3U VPX |
68G5 3U VPX | 3U OpenVPX, Dual Core ARM® Cortex® A9 @ 800 MHz, 3 Function Module Slots | マルチファンクション I/O ボード | 3U VPX |
8810A | Synchro/Resolver Angle Position Indicator | シンクロ / レゾルバ | 計測器 |
68ARM1 | ARM ARM® Cortex®-A9 Dual Core 800 MHz Processor - Up to 3 Functions | シングルボードコンピューター (SBC) | 3U VPX |
NIU2A-ES2 | Rugged Ethernet Switch | 堅牢型スイッチ | System |
VPX55-3HU | 400 Watts DC/DC Power Line Conditioner | 堅牢型電源 | 3U VPX |
Data Acquisition System | Flight Test, Engine Power, Crew Controls | 堅牢型COTSシステム | System |
IEEE 1394 (Firewire) | High-speed serial communications | Function Modules (VPX, VME, cPCI, PCIe) | |
2250A | Phase Angle Voltmeter | シンクロ / レゾルバ | 計測器 |
68ARM2 | Rugged, Cybersecure & Anti-Tamper Single Board Computer | シングルボードコンピューター (SBC) | 3U VPX |
68PW1 | Single-axis PWM servo motor drive | PWM- Servo Motor Drives | 3U VPX |
Data Concentrator Units (DCU) | Host the utilities functions, eliminating several boxes and hundreds of pounds of cable. | 堅牢型COTSシステム | System |
Serial Communications | RS-232, RS-422, RS-485 | Function Modules (VPX, VME, cPCI, PCIe) | |
VPX55HS | 800 Watts DC/DC | 堅牢型電源 | 3U VPX |
CANBus | Independent, isolated channels | Function Modules (VPX, VME, cPCI, PCIe) | |
Synchro/Resolver Measurement | 4 Channels per module Auto Ranging 2 - 90 V L-L | Function Modules (VPX, VME, cPCI, PCIe) | |
68ARM4 | Supports 2 Function Modules - Over 100 to choose from | シングルボードコンピューター (SBC) | 3U VPX |
67C3 | 6U OpenVPX, BF533 / Cyclone® III, 6 Function Module Slots | マルチファンクション I/O ボード | 6U VPX |
5300 | Synchro/Resolver High Accuracy Simulator | シンクロ / レゾルバ | 計測器 |
68PPC2 | SBC - T2080 Processor 2 Function Modules | シングルボードコンピューター (SBC) | 3U VPX |
Fire Control and Targeting System | MIL-STD-1553, Synchro/Resolver Simulation and Measurement | 堅牢型COTSシステム | System |
VPX68 | 400 Watts, DC/DC, Meets MIL-STD-704A through F | 堅牢型電源 | 3U VPX |
IMA for Fixed Wing Aircraft | AFDX, 1553, CANBus, LVDT/RVDT, A/D, D/A, Discrete I/O and PS | Value Added System Integration | |
Synchro/Resolver Simulation | 1 - 3 Channels per module, .25 VA - 2.2 VA | Function Modules (VPX, VME, cPCI, PCIe) | |
LVDT/RVDT Measurement | 4 channels per module | Function Modules (VPX, VME, cPCI, PCIe) | |
67G6 | Up to 6 Function Modules | マルチファンクション I/O ボード | 6U VPX |
VPX-56-3HU | 400 Watts Power Line Conditioner - 50 milliseconds of holdup time | 堅牢型電源 | 3U VPX |
Flight Control Computers (FCC) | Supports several platform flight control systems | 堅牢型COTSシステム | System |
LVDT/RVDT Simulation | 2 Channels at 1.5VA or 3 Channels at .5VA | Function Modules (VPX, VME, cPCI, PCIe) | |
VPX55-BEHU | DC/DC BAck End Holdup Module | 堅牢型電源 | 3U VPX |
Thermocouple and RDT Measurement | Interfaces with all standard NIST thermocouple types | Function Modules (VPX, VME, cPCI, PCIe) | |
75G5 | 3U cPCI, ARM / Xilinx® Zynq, 3 Function Module Slots | マルチファンクション I/O ボード | 3U cPCI |
VPX57-31 | 500 Watts DC/DC 270 V DC Input up to 6 outputs | 堅牢型電源 | 3U VPX |
Integrated vehicle health monitoring system | Up to 9 Functions | 堅牢型COTSシステム | System |
Time-Triggered Ethernet | Also supports AFDX | Avionics Data Bus | |
67PPC2 | Six I/O Function Module Slots | シングルボードコンピューター (SBC) | 6U VPX |
Strain Gauge | Used in applications requiring pressure, weight and stress transducers | Function Modules (VPX, VME, cPCI, PCIe) | |
75D4-H2 | I/O & Comm Board w/Gig-E Switch | マルチファンクション I/O ボード | 3U cPCI |
VPX57HS | 725 Watts +270 VDC input alignment of SOSA™ | 堅牢型電源 | 3U VPX |
Mission Computers (MC) | Provides around-the-clock, intelligent diagnostics on critical missions | 堅牢型COTSシステム | System |
A/D - Analog to Digital | 1.25 to 100 V input options (9 Modules) | Function Modules (VPX, VME, cPCI, PCIe) | |
D/A - Digital to Analog | Up to 80 Vdc outputs | Function Modules (VPX, VME, cPCI, PCIe) | |
78C2 | 6U cPCI, BF533 / Cyclone® II, 5 Function Module Slots | マルチファンクション I/O ボード | 6U cPCI |
64ARM1 | Up to 6 Functions | シングルボードコンピューター (SBC) | VME |
75PS4 | 75 and 150 Watt Versions DC/DC | 堅牢型電源 | 3U cPCI |
Nano Remote Data Concentrator | Dual-Redundant MIL-STD-1553 BC, RT & MT and 8 ARINC 429/575 channels | 堅牢型COTSシステム | System |
Discrete I/O | up to 24 channels available as inputs or outputs | Function Modules (VPX, VME, cPCI, PCIe) | |
Digital I/O | 24 TTL Channels, Programmable I/O | Function Modules (VPX, VME, cPCI, PCIe) | |
64G5 | 6U VME, ARM / Xilinx® Zynq, 6 Function Module Slots | マルチファンクション I/O ボード | VME |
75ARM1 | 3 Function Modules | シングルボードコンピューター (SBC) | 3U cPCI |
VPX56H-6 | 1,000 Watts AC/DC | 堅牢型電源 | 6U VPX |
68G5-S/R | Synchro/Resolver Measurement and Simulation | シンクロ / レゾルバ | 3U VPX |
Remote Interface Units (RIU) | Communicate with higher-level computing systems | 堅牢型COTSシステム | System |
75G5-S/R | Synchro/Resolver Measurement and Simulation | シンクロ / レゾルバ | 3U cPCI |
64CS4 | Digital-to-Synchro/Resolver (D/S)I/O + 5 Function Module Slots, 6U VME, BF533 / Cyclone® II 5 | シンクロ / レゾルバ | VME |
73SD4 | PC/104 Synchro/Resolver Measurement, Convention Cooled | シンクロ / レゾルバ | |
79C3 | PCIe, 3 Function Module Slots | マルチファンクション I/O ボード | PCIe |
NIU1A | Small Size Low power | 堅牢型COTSシステム | System |
73DS2 | PC/104 Synchro/Resolver Simulation, Convection Cooled | シンクロ / レゾルバ | |
VPX56H2-6 | 1,400 Watts Conduction Cooled 5 Outputs | 堅牢型電源 | 6U VPX |
76CS3 | Digital-to-Synchro/Resolver (D/S) and Digital-to-LVDT/RVDT (DLV) stimulus + 5 Function Module Slot | シンクロ / レゾルバ | PCIe |
75PPC1 | 2 Function Modules | シングルボードコンピューター (SBC) | 3U cPCI |
44PA1 | 30 VA Synchro Booster Amplifier | シンクロ / レゾルバ | |
NIU2A | COTS SFF System | 堅牢型COTSシステム | System |
79G5 | can be configured with up to three NAI smart I/O and communication function modules | マルチファンクション I/O ボード | PCIe |
55GS1 | 25 Watts DC/DC | 堅牢型電源 | Brick |
NIU3A | Xilinx® UltraScale+ Dual or Quad Core ARM Cortex®A53 Processors | 堅牢型COTSシステム | System |
NIU3E | Multifunction I/O System with 10 GB Fiber Optic & 1 GB Copper Ethernet Switch | 堅牢型COTSシステム | System |
SIU31 | Ethernet interface | 堅牢型COTSシステム | System |
76C2 | PCI, 3 Function Module Slots | マルチファンクション I/O ボード | PCI |
55J1 | 50 Watts DC/DC | 堅牢型電源 | Brick |
75INT6 | Intel® Core™ i7-1185GRE Processor (Tiger Lake) w/ 4 Cores, to 2.8 GHz | シングルボードコンピューター (SBC) | 3U cPCI |
SIU32S | Highly configurable Modular Open Systems Approach (MOSA) | 堅牢型COTSシステム | System |
SIU33 | Up to 9 Functions | 堅牢型COTSシステム | System |
55K1 | 75 Watts DC/DC | 堅牢型電源 | Brick |
SIU34 | Configure with up to 12 I/O and Communication Function Modules | 堅牢型COTSシステム | System |
SIU35 | Up to 15 Functions | 堅牢型COTSシステム | System |
55LS1 | 100 Watts DC/DC | 堅牢型電源 | Brick |
56GS1 | 25 Watts AC/DC | 堅牢型電源 | Brick |
SIU36 | Up to 18 Functions Small Form Factor System | 堅牢型COTSシステム | System |
56J1 | 50 Watts AC/DC | 堅牢型電源 | Brick |
56K1 | 75 Watts AC/DC | 堅牢型電源 | Brick |
56M1 | 150 Watts AC/DC | 堅牢型電源 | Brick |
56RS1 | 300 Watts AC/DC -Standard output voltages: 24V, 28V | 堅牢型電源 | Brick |
56RS3 | 300 Watts AC/DC - Standard output voltages: +15V, +24V, +28V | 堅牢型電源 | Brick |
56TS1 | 500 Watts AC/DC | 堅牢型電源 | Brick |
